22 TRD Pro / Heritage Grille Camera Mount Bracket

Hey Everyone,
I just wanted to come back to this thread and share some photos of the support brackets that were developed for the TRD Pro grill conversion kit. These were designed to stiffen the light bar in this location to reduce the risk of damage to the grill as we have seen with other companies products thus far. With this support bracket ready for production all TRD Pro grill conversion lighting kits have been taken off pre-order and will begin to ship out as soon as possible.
Best,
Brandon

https://www.bajadesigns.com/product...-toyota-2022-23-tundra/?page=1&vid=3921326335



One of my TRD Pro marker lights is retaining water. Covered under warranty (I have a TRD Pro) but dealer hasn't been able to locate a part number for a replacement. Anyone else having any luck procuring the grill marker lights? Are they just not being sold now?



Guess it'll be a long wait before I can get the lights replaced then lol



@Prohit how is your 3D printed bracket for the little amber lights working out? I'm interested in doing the same thing with my Platinum when I change the grille.



It’s held up great so far. No movement and has been through some different temperature swings.



My oem trd pro grill mounting tabs don’t have threads to where I can screw the light bracket to. What gives? I cant screw them in



Has anyone wired the 3 marker lights to parking lights on a limited package? What wires are used? I don't want them coming on with the ignition like the Rave video shows. Not sure if this has been covered in a previous post, I didn't see it when searching.



Has anyone wired up the aliexpress light bar up. I can’t get it to work with my cali switch using a relay. From the Cali switch black and white are ground. Green goes to the relay and red goes to the battery. If I am doing something incorrect let me know.



I tapped mine into a light green wire on the headlight. Passenger side! I'll see if I can snap a picture tonight if needed. They are on any time the truck headlights are on.



Does the relay click when you activate the switch?



That would be great! Thanks.



I didn’t hear anything but I would probably need someone to press for me to be sure because it’s in the passenger side by the battery. Did I do anything wrong in the wiring



I don't have the wiring diagram for cali raised switches, otherwise I'd be able to help a bit more. If the relay doesn't click, then it's not wired correctly somewhere.



Where did you get the "tundra" in-lay on the front of your truck? And what color is it exactly?
Thanks!



Different question. Does anyone’s Ali express light bar actually work. Wired mine to be on and skipped the switch and still wouldn’t turn on.



@eddiefromcali how did you attach the ABS tabs to the grill frame? Looks great!



Self tappers



Appreciate it. I think I’ll give it a try.



For those of you who have upgraded from a TRD Off road (honeycomb) to the Heritage/PRO grille, would anyone be willing to sell the OEM camera mounting bracket from the honeycomb grille? Or happen to have a picture of that part number? i searched and can not find anything online.



I've got ones I designed .. 3D printed .. for sale if you're interested. $25 shipped .. check my thread below!

https://www.tundras.com/threads/for-sale-trd-pro-or-sport-grill-camera-brackets.113612/



Etsy links for those that want the TRD PRO or TRD OR Brackets:
https://creatoriq.cc/44L0QFm




TRD PRO:
https://creatoriq.cc/3r85Fuq



Any tips. I’m stuck at the block…



Anyone know how to disconnect th block heater? I can’t get the front off because of it.



The disconnect is in the passenger wheel well you’ll need to open it up to unhook. Trace the block heater cord from the front to the wheel well not the block



Silly question but what screws did you use to mount it to the grill? My markers arrived but I didn't want to hack job it lol

Is there a special part number I need for it or is there a screw I just jack from the old grill.



You the Goat!!!
